POSTEK E | Ei Series

Commercial
Barcode Label Printer

EXQUISITE SIMPLIFIED DESIGN
DELIVERS THE ULTIMATE USER EXPERIENCE

Model
E200
E300

Wi-Fi
E200i
E300i

Highest print speed

6ips

Maximum print width

108mm

Maximum print length

4000mm

Printing resolution

203dpi
more specs

Highest print speed

4ips

Maximum print width

106mm

Maximum print length

2000mm

Printing resolution

300dpi
more specs

Highest print speed

6ips

Maximum print width

108mm

Maximum print length

4000mm

Printing resolution

203dpi
more specs

Highest print speed

4ips

Maximum print width

106mm

Maximum print length

2000mm

Printing resolution

300dpi
more specs

EXQUISITE SIMPLIFIED DESIGN

DELIVERS THE ULTIMATE USER EXPERIENCE

OVERVIEW


As men of great wisdom often takes the looks of the folly, great art conceals itself in the disguise of simplicity. Any intelligent fool can make things bigger and more complex, it takes a touch of genius – and a lot of courage to move in the opposite direction.

Introducing the new EM210, the industrial grade performance in a sleek and concise profile. The small printer body with high media volume combined with industrial level performance, making the EM210 the perfect blend between simple design and sophisticated interpretation.

FEATURES

Retractable stand supports media up to 8 inches in diameter

Designed with the full user-experience in mind, the EM210 broke the stereotype with the built-in exterior media stand, making it perfect for high printing volume applications in limited space.

Clear and concise  structural design  allows for maximum  efficiency

In the compact body of the EM210, our strive for ease of use can be found around every corner. With designs like the Left & Right structure that clearly separates the operation area and the printing area, the operation of the printer is easier than ever.


Customizable  extended modules  provide potential  for true cordless  operation

With extensible functions like Wi-Fi, Bluetooth, the Ei Series is up to task for handling all situations with ease. （only supported on Ei Series）

The EM series is manufactured with durable printhead and industrial grade components, making the printout a delightful sight to see.

More information
Product support

POSTEK E | Ei Series

Commercial Barcode Label Printer

Model: E200
Print Mode:
 Direct Thermal and Thermal Transfer
Print Resolution:
 203 dpi
Max Print Speed: 6 ips
Max Print Width: 4.25″ (108 mm)
Max Print Length: 157″ (4000 mm)
Memory:

8 MB FLASH ROM, 16 MB SDRAM

*HEAT™ Level:
 Ⅰ
Media:

Width: 4.37′′(111 mm) max., 0.98′′(25 mm) min.

Maximum Outer Diameter: 8" (203.2 mm)Inner Diameter: 1" (25.4mm)

Media Thickness: 0.003" ~ 0.006" (0.08 ~ 0.15 mm), including liner

Minimum Label Length:

- Thermal Transfer
Tear-off: 0.2″ (5 mm)
Cutter: A150/A400: 0.79″ (20 mm) , AG120/AG300: 0.51″ (13 mm)
- Direct Thermal
Tear-off: 1.46″ (37 mm)
Cutter: A150/A400: 1.77″ (45 mm), AG120/AG300: 1.97″ (50 mm)

Ribbon:
 Length: 984′ (300 m)max., Outer Diameter: 2.68"(68 mm)max., Inner Diameter: 1" (25.4 mm), Width: 4.3"(110 mm)
Media Sensor:

Reflective (Adjustable) and Transmissive (Two positions)

Fonts:

Five built-in dot matrix fonts, which include Basic Latin and Latin-1 Supplement character sets.User downloadable TrueType fonts.

Barcode Types:

1D Barcode: Code 39, Code 93, Code 128/subset A,B,C, Codabar, Interleave 2 of 5, UPC A/E 2 and 5 add-on, EAN-13/8/128, UCC-128, etc.2D Barcode: MaxiCode, PDF417, Data Matrix, QR Code, CS Code, etc.

Interfaces:

RS-232 Serial, USB DEVICE 2.0

Power Source:

100 - 240 V， 50/60 Hz ;Output: DC 24 V, 2.5 A

Weight:

3.08 kgs

Dimensions:

W 9.53" (242 mm) x D 13.7" (348.5 mm) x H 7.8" (199 mm)

(With media stand in a expanded state)

Operating Environment:

Temperature: 32°F ~ +104°F (0°C ~ 40°C)Relative humidity: 5% - 90% non-condensing

Storage Environment:

Temperature: -40°F ~ +140°F (-40°C ~ 60°C)Temperature: 5% - 90% non-condensing

Optional Items：

RS-232 Serial Port (Factory dependent)

Wi-Fi, Bluetooth, Guillotine Cutter, 10/100 M Adaptive Ethernet Port,

Rotary Cutter, External Rewinder, Media Guide Adaptor



* HEAT ™ ( Heating Equilibrium Adaptive Tuning ) developed by POSTEK, is a cutting-edge technology in heating control of thermal printheads. With HEAT™, the POSTEK printers can significantly improve their performance in the aspects of printout clarity and print speed. The HEAT™ level represents the fineness of the heating uniformity with level I being the finest.


POSTEK E | Ei Series

Commercial Barcode Label Printer

Model: E300
Print Mode:
 Direct Thermal and Thermal Transfer
Print Resolution:
 300 dpi
Max Print Speed: 4 ips
Max Print Width: 4.17″ (106 mm)
Max Print Length: 79″ (2000 mm)
Memory:

8 MB FLASH ROM, 16 MB SDRAM

*HEAT™ Level:
 Ⅰ
Media Roll:

Width: 4.37′′(111 mm) max., 0.98′′(25 mm) min.

Maximum Outer Diameter: 8" (203.2 mm)Inner Diameter: 1" (25.4mm)

Media Thickness: 0.003" ~ 0.006" (0.08 ~ 0.15 mm), including liner

Minimum Label Length:

- Thermal Transfer
Tear-off: 0.2″ (5 mm)
Cutter: A150/A400: 0.79″ (20 mm) , AG120/AG300: 0.51″ (13 mm)
- Direct Thermal
Tear-off: 1.46″ (37 mm)
Cutter: A150/A400: 1.77″ (45 mm), AG120/AG300: 1.97″ (50 mm)

Ribbon:
 Length: 984′ (300 m)max., Outer Diameter: 2.68"(68 mm)max., Inner Diameter: 1" (25.4 mm), Width: 4.3"(110 mm)
Media Sensor:

Reflective (Adjustable) and Transmissive (Two positions)

Fonts:

Five built-in dot matrix fonts, which include Basic Latin and Latin-1 Supplement character sets.User downloadable TrueType fonts.

Barcode Types:

1D Barcode: Code 39, Code 93, Code 128/subset A,B,C, Codabar, Interleave 2 of 5, UPC A/E 2 and 5 add-on, EAN-13/8/128, UCC-128, etc.2D Barcode: MaxiCode, PDF417, Data Matrix, QR Code, CS Code, etc.

Interfaces:

RS-232 Serial, USB DEVICE 2.0

Power Source:

100 - 240 V， 50/60 Hz ;Output: DC 24 V, 2.5 A

Weight:

3.08 kgs

Dimensions:

W 9.53" (242 mm) x D 13.7" (348.5 mm) x H 7.8" (199 mm)

(With media stand in a expanded state)

Operating Environment:

Temperature: 32°F ~ +104°F (0°C ~ 40°C)Relative humidity: 5% - 90% non-condensing

Storage Environment:

Temperature: -40°F ~ +140°F (-40°C ~ 60°C)Temperature: 5% - 90% non-condensing

Optional Items：

RS-232 Serial Port (Factory dependent)

Wi-Fi, Bluetooth, Guillotine Cutter, 10/100 M Adaptive Ethernet Port,

Rotary Cutter, External Rewinder, Media Guide Adaptor



* HEAT ™ ( Heating Equilibrium Adaptive Tuning ) developed by POSTEK, is a cutting-edge technology in heating control of thermal printheads. With HEAT™, the POSTEK printers can significantly improve their performance in the aspects of printout clarity and print speed. The HEAT™ level represents the fineness of the heating uniformity with level I being the finest.


POSTEK E | Ei Series

Commercial Barcode Label Printer

Model: E200i
Print Mode:
 Direct Thermal and Thermal Transfer
Print Resolution:
 203 dpi
Max Print Speed: 6 ips
Max Print Width: 4.25″ (108 mm)
Max Print Length: 157″ (4000 mm)
Memory:

8 MB FLASH ROM, 16 MB SDRAM

*HEAT™ Level:
 Ⅰ
Media Roll:

Width: 4.37′′(111 mm) max., 0.98′′(25 mm) min.

Maximum Outer Diameter: 8" (203.2 mm)Inner Diameter: 1" (25.4mm)

Media Thickness: 0.003" ~ 0.006" (0.08 ~ 0.15 mm), including liner

Minimum Label Length:

- Thermal Transfer
Tear-off: 0.2″ (5 mm)
Cutter: A150/A400: 0.79″ (20 mm) , AG120/AG300: 0.51″ (13 mm)
- Direct Thermal
Tear-off: 1.46″ (37 mm)
Cutter: A150/A400: 1.77″ (45 mm), AG120/AG300: 1.97″ (50 mm)

Ribbon:
 Length: 984′ (300 m)max., Outer Diameter: 2.68"(68 mm)max., Inner Diameter: 1" (25.4 mm), Width: 4.3"(110 mm)
Media Sensor:

Reflective (Adjustable) and Transmissive (Two positions)

Fonts:

Five built-in dot matrix fonts, which include Basic Latin and Latin-1 Supplement character sets.User downloadable TrueType fonts.

Barcode Types:

1D Barcode: Code 39, Code 93, Code 128/subset A,B,C, Codabar, Interleave 2 of 5, UPC A/E 2 and 5 add-on, EAN-13/8/128, UCC-128, etc.2D Barcode: MaxiCode, PDF417, Data Matrix, QR Code, CS Code, etc.

Interfaces:

RS-232 Serial, USB DEVICE 2.0

Wi-Fi:

Supports IEEE802.11a/b/g/n, 1T1R&BT5.0

Power Source:

100 - 240 V， 50/60 Hz ;Output: DC 24 V, 2.5 A

Weight:

3.08 kgs

Dimensions:

W 9.53" (242 mm) x D 13.7" (348.5 mm) x H 7.8" (199 mm)

(With media stand in a expanded state)

Operating Environment:

Temperature: 32°F ~ +104°F (0°C ~ 40°C)Relative humidity: 5% - 85% non-condensing

Storage Environment:

Temperature: -40°F ~ +140°F (-40°C ~ 60°C)Temperature: 5% - 85% non-condensing

Optional Items：

RS-232 Serial Port (Factory dependent)

Wi-Fi, Bluetooth, Guillotine Cutter, 10/100 M Adaptive Ethernet Port,

Rotary Cutter, External Rewinder, Media Guide Adaptor



* HEAT ™ ( Heating Equilibrium Adaptive Tuning ) developed by POSTEK, is a cutting-edge technology in heating control of thermal printheads. With HEAT™, the POSTEK printers can significantly improve their performance in the aspects of printout clarity and print speed. The HEAT™ level represents the fineness of the heating uniformity with level I being the finest.


POSTEK E | Ei Series

Commercial Barcode Label Printer

Model: E300i
Print Mode:
 Direct Thermal and Thermal Transfer
Print Resolution:
 300 dpi
Max Print Speed: 4 ips
Max Print Width: 4.17″ (106 mm)
Max Print Length: 79″ (2000 mm)
Memory:

8 MB FLASH ROM, 16 MB SDRAM

*HEAT™ Level:
 Ⅰ
Media Roll:

Width: 4.37′′(111 mm) max., 0.98′′(25 mm) min.

Maximum Outer Diameter: 8" (203.2 mm)Inner Diameter: 1" (25.4mm)

Media Thickness: 0.003" ~ 0.006" (0.08 ~ 0.15 mm), including liner

Minimum Label Length:

- Thermal Transfer
Tear-off: 0.2″ (5 mm)
Cutter: A150/A400: 0.79″ (20 mm) , AG120/AG300: 0.51″ (13 mm)
- Direct Thermal
Tear-off: 1.46″ (37 mm)
Cutter: A150/A400: 1.77″ (45 mm), AG120/AG300: 1.97″ (50 mm)

Ribbon:
 Length: 984′ (300 m)max., Outer Diameter: 2.68"(68 mm)max., Inner Diameter: 1" (25.4 mm), Width: 4.3"(110 mm)
Media Sensor:

Reflective (Adjustable) and Transmissive (Two positions)

Fonts:

Five built-in dot matrix fonts, which include Basic Latin and Latin-1 Supplement character sets.User downloadable TrueType fonts.

Barcode Types:

1D Barcode: Code 39, Code 93, Code 128/subset A,B,C, Codabar, Interleave 2 of 5, UPC A/E 2 and 5 add-on, EAN-13/8/128, UCC-128, etc.2D Barcode: MaxiCode, PDF417, Data Matrix, QR Code, CS Code, etc.

Interfaces:

RS-232 Serial, USB DEVICE 2.0

Wi-Fi:

Supports IEEE802.11a/b/g/n, 1T1R&BT5.0

Power Source:

100 - 240 V， 50/60 Hz ;Output: DC 24 V, 2.5 A

Weight:

3.08 kgs

Dimensions:

W 9.53" (242 mm) x D 13.7" (348.5 mm) x H 7.8" (199 mm)

(With media stand in a expanded state)

Operating Environment:

Temperature: 32°F ~ +104°F (0°C ~ 40°C)Relative humidity: 5% - 85% non-condensing

Storage Environment:

Temperature: -40°F ~ +140°F (-40°C ~ 60°C)Temperature: 5% - 85% non-condensing

Optional Items：

RS-232 Serial Port (Factory dependent)

Wi-Fi, Bluetooth, Guillotine Cutter, 10/100 M Adaptive Ethernet Port,

Rotary Cutter, External Rewinder, Media Guide Adaptor


* HEAT ™ ( Heating Equilibrium Adaptive Tuning ) developed by POSTEK, is a cutting-edge technology in heating control of thermal printheads. With HEAT™, the POSTEK printers can significantly improve their performance in the aspects of printout clarity and print speed. The HEAT™ level represents the fineness of the heating uniformity with level I being the finest.
